Accelerometer Sensor A2512 Amplified

Hubungi Kami




Description

Akselerometer A2512 yang diperkuat telah dirancang untuk pengujian struktural dinamis dalam kondisi medan berat. Sensor MEMS terintegrasi yang akurat, kokoh, dan sepenuhnya tahan cuaca ini dapat digunakan dari aplikasi frekuensi nol hingga menengah yang membutuhkan kebisingan rendah dan stabilitas jangka panjang yang andal.

Tersedia dalam konfigurasi uniaksial, biaksial, dan triaksial dengan pilihan sensitivitas ±2g, ±5g, ±10g, ±25g, dan ±50g. Sensor dibuat sesuai pesanan dengan pilihan panjang kabel. Versi tanpa penguat, A1512, juga tersedia untuk panjang kabel di bawah 300 kaki.

Setiap model dapat dipasang dengan sangat cepat dan aman melalui penggunaan berbagai pilihan pemasangan dan aksesori kami.




Feature

  • Completely reusable
  • Designed to exceed IP67
  • Nitrogen gas damped
  • High stability
  • Low power requirements
  • Various mounting options available
  • Industrial cable, custom lengths
  • N.I.S.T. traceable calibration available
  • 9-30 Vdc input voltage range
  • High differential output (±4.0 Vdc)
  • Responds down to 0 Hz

Spesification

UNIAXIAL MODELS UA2512-002 UA2512-005 UA2512-010 UA2512-025 UA2512-050 UA2512-100
BIAXIAL MODELS BA2512-002 BA2512-005 BA2512-010 BA2512-025 BA2512-050 BA2512-100
TRIAXIAL MODELS TA2512-002 TA2512-005 TA2512-010 TA2512-025 TA2512-050 TA2512-100
RANGE (g)1 ±2 ±5 ±10 ±25 ±50 ±100
FREQUENCY RESPONSE [NOMINAL, 3dB] (Hz) 0-300 0-400 0-600 0-900 0-1200 0-1400
DIFFERENTIAL SENSITIVITY (mV/g) 1000 400 200 80 40 20
EXCITATION VOLTAGE 9-30 Vdc
OUTPUT ±2.0 Vdc Full Scale Output
OPERATING TEMPERATURE2 -58° to +176 °F (-50° to +80 °C)
SIZE 2.45 x 1.80 x 1.10 in (62.2 x 45.7 x 27.9 mm)
HOUSING Machined 6061 Aluminum Alloy
CORROSION RESISTANCE Hard Anodized Clear (MIL-A-8625 Type III)
WEATHER PROTECTION Designed to exceed IP67



1 Higher ranges are available, contact BDI for more details
2 Temperature limit based on instrumentation cable operating temperatures, call BDI for wide temperature range cable options.
