Description
The soil contains many substances such as organic acid, inorganic acid, alkali and salt, due to the different content of various substances, so the soil shows different ph value.Usually the pH in the range of 6.5-7.5 soil is called the neutral soil.RK500-02 pH sensors measure the pH value should be a good solution without professional calibration instruments, complex operation, expensive and difficult to carry, can be for continuous measurement of soil, waste water pH value, suitable for agriculture, sewage treatment plant, chemical industry, printing and dyeing, paper making, pharmacy, electroplating and environmental protection and other fields.
Feature
ISTALLATION & ACCESSORIE
1.When used for online soil measurement, transmitting module and probe is waterproof joint connection(gland) ,can not be separated, probe(with filter and protective cap) and transmitting module buried directly to use,show in figure.
2. If need to use in a pool or tank, you can choose submersible mounting bracket, between the probe and transmitting module use BNC connectors(show in figure 2), convenient to probe through the mounting bracket.
ACCESSARIES
Spesification
|
Item |
Technical Specification |
|||
|
Range |
0-14PH | |||
|
Resolution |
0.01PH | |||
|
Accuracy |
±0.3PH | |||
|
Supply |
Mark on the label |
|||
|
Output Signal |
4-20mA,0-5V,0-2V,RS485 |
|||
|
Response time |
<10s(in water) |
|||
|
Stability |
≤0.02PH/24h |
|||
|
Operating Temperature |
0-+80? |
|||
| Dimension | Probe: ?28*160mm | |||
| Ingress Protection | IP67 | |||
| Storage | 10-60?@20%-90%RH | |||
