Description
RK510-01 is a high accuracy, high sensitivity of soil moisture measuring instrument.The product on the principle of electromagnetic pulse (FDR:Frequency Domain Reflectometry) to measure the dielectric constant of the soil, stainless steel probe is inserted into the soil surface or soil profile to quickly online measurement of soil volumetric moisture content, the method is the most popular method of soil moisture measurement.It can be used permanently embedded in the soil.Soil moisture sensor can be widely applied to the soil moisture monitoring, water-saving irrigation, greenhouse control, fine agriculture, hydrology and meteorology, and other fields, road monitoring.
Feature
PRODUCT DETAILS
DIMENSION
PRODUCT DETAILS
Product Material
Product working principle
Product function
Spesification
|
Item |
Technical Specification |
||
|
Range |
0-100%,0-50%,0-30%, |
||
|
Accuracy |
±2%(0-50%) |
||
|
Output Signal |
4-20mA ,0-5V,0-2V,RS485 optional |
||
|
Response Time |
<1s |
||
|
Supply |
5VDC, 12-24VDC |
||
|
Effective measurement area |
With the center of the probe diameter is 70mm, high 70mm cylinder |
||
|
Housing |
ABS |
||
|
Dimensions |
Ø50*208mm(probe:Ø4*78mm) |
||
|
Operating Temperature |
-30?-+70? |
||
|
Ingress Protection |
IP67 |
||
|
Storage |
10-60?@20%-90%RH |
||
|
Probe material |
316L stainless steel |
||
